Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter

    Buy cheap Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter from wholesalers

    Buy cheap Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter from wholesalers
    • Buy cheap Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter from wholesalers
    • Buy cheap Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter from wholesalers

    Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter

    Ask Lasest Price
    Brand Name :
    Model Number : S-300-5
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 10000pcs/month
    Delivery Time : 3-10days
    • Product Details
    • Company Profile

    Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter



    S-300-5 Single Output Voltage 300W 60A 5V Dc Switching Power Supply Module

    Model

    S-300-5

    AC input voltage range(V)

    AC 110/220V±15%(switch replacement)

    AC Input current(max)

    6.5A /115V,4A /230V

    Frequency (Hz)

    50/60Hz

    Efficiency

    90% Typ(230VACFull Load)

    Inrush current(A)

    Current 25A/115V 50A/230V cold start

    Leakage current(mA)

    <3.5mA/240VAC

    Output Voltage(V)

    5V DC

    Voltage Regulation

    ±10%

    Output Current(A)

    60A

    Current Range (A)

    0~60A

    Rated Power(W)

    300W

    Start time,hold-up time(ms)

    Ton≤200ms,Td≥30ms @230Vac Full Load

    Rise time(ms)

    Typ:100ms @230Vac Full Load

    Ripple/Noise(mVp-p)

    150mVp-p

    working Temperature (°C)

    -40°C - +65°C(refer derating curve)

    Storage Temperature(°C)

    -20°C - +60°C

    Humidity

    20% - 90% RH non condensing

    Over voltage Protection

    >115%-135% Rated output voltage(13.8-16.2V)

    Over load Protection

    >105%-150% Auto recovery

    Short circuit Protection

    Latched

    Packing Size / Product Size(cm)

    22*11.7*5.5/ 21.5*11.2*5

    Gross Weight / Net Weight(kg)

    0.865 /0.825

    Product Description

    Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter

    Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter


    Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter

    Switching Power Supply 5V 300W 60A Lighting Transformer AC 110V 220V to DC 5 volt Converter Adapter

    Specification

    item

    value

    Place of Origin

    China


    Guangdong

    Brand Name

    Megbox

    Model Number

    S-300-5

    Output Power

    300W

    Output Type

    Single

    Input Voltage

    AC100-240V

    Output Voltage

    5V

    Output Frequency

    50-60Hz

    Output Current

    5A

    Product Name

    Swtiching Power

    Application

    LED Strip

    Warranty

    2 Years

    Certification

    CE

    Type

    Constant Voltage

    Efficiency

    95%

    Weight

    0.86KG

    Size

    215*112*50mm

    Protections

    OPP OVP SCP OCP

    Name

    AC DC Power Module Converter
