    DC 12V LED DMX Decoder , Px24506 Dmx512 Decoder For RGB Strip Lights

    Px24506 Led Dmx Decoder Dmx512 Amplifier 12v Controller For Rgb Strip Lights


    Description - Text Version

    PX24506 DMX512 Decoder Driver Amplifier Controller For RGB LED Strip Module 9A DMX512 Amplifier DC12V-24V
    Product introduction:

    1.Compliant with DMX512/1990;

    2.256-level brightness, full-color RGB color control;

    3.Each channel output of 3 channels maximum 3A;

    4.Control system, can realize synchronous control;

    5.Convert the internationally popular DMX512/1990 standard digital control signal into PWM constant voltage drive;

    6.Light color control light 1~3 colors;

    7.The DMX address can be set freely (the DMX address can be set by the DIP switch);

    8.3-channel output, 256-level grayscale for each channel, full-color drive control;

    9.10 RGB self-test modes, 8-level change speed;

    10.It can be connected to a power expander to amplify the power. Basic parameters:

    11. Input voltage: DC12-24V

    12. Output channel: 3 channels

    13.Output current: 3A*3CH

    14. Size: L86*W51*H18mm

    15.Weight: about 110g

    16.Input signal: DMX-512/1990 digital signal

    17. Output type: PWM

    18. Grayscale: 256 levels

    Specification
    item
    value
    Lighting solutions service
    Lighting and circuitry design, Project Installation
    Product Weight(kg)
    0.11
    Place of Origin
    China
    Guangdong
    Brand Name
    Lebeisenf
    Type
    MANUAL SWITCH
    Max. Load Power
    216W
    Connection Mode
    common anode
    Product name
    DMX Decoder
    Application
    RGB Led Strip Lighting
    Input Voltage
    DC12V-DC24V
    Output channel
    3 Channels RGB
    Output current
    3A*3CH
    Input signal
    DMX512/1990 Standard Digital Signal
    Output signal
    Constant Voltage PWM Signal
    Output power
    12V<108W;24V<216W
    Size
    L86*W51*H18mm
    Certificates
    CE ROHS
    Product Description
